DGP 1520 ME
High-power, open three-phase generator, operating in automatic mode, manual mode, signal mode, or test mode. Limitless stellar energy, pure power.
Power (PRP / ESP):
1382 / 1516 kVA (1106 / 1213 kW)
VERSION:
Open
VOLTAGE:
400/230V
EMISSIONS LEVEL: EU Stage 0
CE DECLARATION OF CONFORMITY
DGP 1520 ME
DGP 1520 ME
DGP 1520 ME
DGP 1520 ME
DGP 1520 ME
DGP 1520 ME
PRODUCT DETAILS
VERSION
Open
Fuel
Diesel
Voltage
400/230V
RPM
1500
Number of phases
3
L (mm)
5800
W (mm)
2150
H (mm)
2600
Weight (Kg)
10150
Engine make and model
PERKINS 4012-46TWG3A Trop
Type of regulation
Electronic
Refrigeration
Water-cooled
Emissions
EU Stage 0
Consumption 50%
151 l/h
Consumption 75%
213 l/h
Consumption 100% PRP
283 l/h
Consumption 100% ESP
318 l/h
Alternator make and model
MECCALTE ECO43 VL4 A
Type of alternator regulation
DER1
Switch model
Schneider ComPact 2500A 4P
Amps ESP (A)
2188,2
Make and model
DSE 7320 MKII
DGP 1520 ME
Range High Power
| 50Hz
Do you need an ATS for your installation?
CONTACTORS TRANSFER SWITCHES
Switching panels between mains and genset with Schneider Electric contactors and enclosure from the same manufacturer. With mechanical and electrical interlocking and switching management from the control panel. They have an optional mains failure detector.
REMOTELY OPERATED MOTORISED TRANSFER SWITCH (RTS)
Transfer switches with remote-operated 4-pole fully visible break. They allow in-load transfer of two three-phase sources via remote-voltage-free contacts, from an external automatic controller, using pulse logic or a switch.
They are designed for use in low-voltage power systems where a brief interruption of load power during transfer is acceptable.
